Stormdrain Pipes

Jhaymarts Stormdrain Pipes are best substitute for the heavy, low efficient and high installation and maintenance cost, cement culverts. Corrugated outside wall to withstand external pressure and plain inside wall for smooth flow.It can also be used for non pressure water conveyance for irrigation, aqua farms, and drainage and sewer lines.

It uses compounded recycled PE formulated to withstand external pressures.



Nominal
Diameter		 Outside
Diameter		 Inside
Diameter		 Corrugation
Height

Pitch

Length
in. mm. mm. mm. mm. M.
8 225 192 15.00 24.00 6
10 280 242 17.50 28.00 6
12 330 288 19.50 32.00 6
14 385 338 21.50 32.50 6
16 450 396 25.00 38.00 6
18 510 444 31.00 41.00 6
20 560 491 32.00 43.00 6
24 665 591 35.00 56.00 6
30 822 740 35.00 66.00 6
36 965 890 37.00 68.00 6



>
